A larger carburetor is essential to improve engine setup.
The flat slide carburettor offers the advantage that the intake path is shorter due to the shortened slide. This improves the engine's throttle response. Manual choke. The venturi tube of the carburetor is machined to improve airflow.
Air filter connection diameter: 50mm
Diameter intake manifold: 35mm
Our carburetors are available in the following sizes:
19mm: main jet 85, secondary jet 40, Powerjet 32
21mm: main jet 95, secondary jet 40, Powerjet 32
24mm: main jet 110, secondary jet 40, Powerjet 32
28mm: main jet 130, secondary jet 40, Powerjet 32
30mm: main jet 136, secondary jet 40, Powerjet 32
32mm: main jet 142, secondary jet 40, Powerjet 32
34mm: main jet 142, secondary jet 45, Powerjet 32
38mm: main jet 142, secondary jet 45, Powerjet 32
scope of delivery
carburetor and intake rubber
